AMAT 0190-05410 Card, Dual Industry Pack Carrier, cPCI Bus

AMAT    0190-05410 Card, Dual Industry Pack Carrier, cPCI Bus

Introduction

The AMAT 0190-05410 is a Dual Industry Pack (IP) Carrier Card utilizing the cPCI (CompactPCI) Bus architecture.

In the semiconductor tool hierarchy, this card acts as a "mother-board" for smaller, specialized "mezzanine" modules (Industry Pack modules).

It enables the tool's central controller to communicate with various sensors, actuators, and analog/digital I/O devices by providing two expansion slots on a single cPCI 3U or 6U form factor.

2. Technical Parameter Table

3. Related Models

The 0190-05410 is part of the modular computing sub-rack. Related communication and processing boards include:

AMAT 0190-24008: Single Board Computer (SBC) 3U 4HP, often the "master" to this carrier.

AMAT 0190-05996: PCB Assy, Analog I/O (often an IP module mounted on this carrier).

AMAT 0100-09023: Mini Digital I/O Board.

AMAT 0190-07502: cPCI Power Board (supplies power to the backplane housing this card).

4. Application Cases

Real-time Sensor Integration: Used in Centura or Endura platforms to house IP modules that read high-speed vacuum gauges or optical endpoint detectors.

Gas Box Control: Acts as the interface for mass flow controller (MFC) digital-to-analog conversion modules.

Legacy Tool Modernization: Frequently found in upgraded P5000 systems where the control architecture has been migrated to a cPCI-based VME-replacement system.

5. Product Advantages and Features

Modular Versatility: Allows engineers to mix and match different I/O functions (Digital, Analog, Serial) on a single cPCI slot, saving valuable rack space.

Hot-Swap Compatibility: Designed for the cPCI backplane, which supports high availability and easier maintenance in 24/7 fab operations.

Ruggedized Design: Built for high MTBF (Mean Time Between Failure), featuring high-quality locking connectors to withstand the vibration of turbo pumps and robotic movements.

High-Density I/O: By carrying two modules per card, it doubles the I/O density compared to standard single-function boards.

6. Other Models in the Same Series

Within the 0190-XXXXX electronics and computing series:

0190-05411: Single Industry Pack Carrier variant.

0190-06000 Series: Specialized Video/GUI interface cards.

0190-20000 Series: Advanced 300mm platform control modules (e.g., DeviceNet scanners).

7. Installation and Maintenance

Installation

Module Mounting: Secure the Industry Pack (IP) mezzanine modules onto the 0190-05410 carrier using the four mounting standoffs before inserting the carrier into the tool.

Seating: Slide the card into the designated cPCI slot on the tool’s controller rack. Ensure the ejector handles are fully engaged.

Software Mapping: Once installed, the tool software must be configured to recognize the specific IP modules residing in Slot A and Slot B of the carrier.

Maintenance

Contact Cleaning: Periodically inspect the cPCI gold fingers for oxidation; clean with an approved electronic-grade contact cleaner if necessary.

Firmware Verification: Ensure the carrier's logic bridge (FPGA/CPLD) is compatible with the system's current software version.

8. Unique Product Description

The AMAT 0190-05410 is the "Swiss Army Knife" of the tool's control rack.

By providing a bridge between the high-speed cPCI backplane and specialized Industry Pack modules,

it allows the tool to adapt to varied process requirements—whether it's monitoring a specific gas flow or controlling a precise mechanical arm—all without replacing the core computer architecture.
