CTI 2500C-C300 CPU with 512K User Memory

2500C-C300 CPU with 512K User Memory

The 2500C-C300 CPU provides discrete, analog, loop, advanced mathematical, and high-speed sequential control capability for your CTI 2500 Series® Compact control system.

Features

Compatible with programs written for Siemens® 555-1101. 555-1103. 555-1105. and CTI 2500-C300

512K user memory

8192 digital / 8192 analog I/O

512 loops / 512 alarms

Built-in Ethernet for programming and MMI

Built-in USB for programming

Profibus-DP master and RS485 Remote I/O ports

Built-in SD flash card slot for firmware update

Digital Input 2500C-16-DI-24V - 16 24V AC/DC Inputs

2500C-16-DI-120V - 16 120/240V AC/DC Inputs

2500C-16-IDI-24V- 16 Isolated 24V AC/DC Inputs

2500C-16-IDI-120V - 16 Isolated 120V AC/DC Inputs

16 isolated or non-isolated inputs,

hot-swappable

Digital Output 2500C-8-IDO-24V - 8 Isolated 24VDC Outputs

2500C-8-IDO-120V - 8 Isolated 120/240VAC Outputs

2500C-16-DO-24V - Sixteen 24VDC Outputs

2500C-16-DO-120V - Sixteen 120VAC Outputs

8 or 16 outputs (8 output modules

are isolated), hot-swappable

Analog 2500C-8-AI - 8 Analog Inputs

2500C-8-AO - 8 Analog Outputs

Wide input and output ranges, no

user calibration, hot-swappable

Relay Output 2500C-8-RL-FC - 8-Point Form-C Relay Outputs

Up to 5A output current per channel,

hot-swappable

Temperature 2500C-8-TC - 8 Thermocouple Inputs

2500C-8-RTD - 8 RTD Inputs

Thermocouple supports J, K, T, E,

R, S, & N and millivolt inputs. RTD

supports 2.3 and 4 wire RTDs. No

user calibration, hot-swappable

Counter* 2500C-4-HSC

4-Channel High Speed Counter

Operates in frequency, period or

counter mode, hot-swappable

Ethernet 2500C-2572-B  Fast Ethernet TCP/IP Adapter

100Mbit communications, supports

CAMP and Modbus-TCP
