GE Multilin 745-W2-P5-G5-HI-A-R Relay, Designed

Operating Environment:Humidity up to 90% non-condensing Weight:4.8kg Voltage Input:60 to 120 V Relay Dimensions:9 , 7 , 7 Overload Withstand:1 second at 80 times rated current, continuous at 3 times rated current Model Number:745-W2-P5-G5-HI-A-R-E Ground Current Relay Input:5 A Display Type:40 character LCD Input Voltage Range:60 to 120V Software Version:EnerVista 745 Setup Operating Temperature:-40"C to +60"C Chassis:745 SR Series Manufacturer:General Electric Multilin Fuse Current Rating:3.15 A Features:[ nhanced Display  igh Control Power  ynamic CT Ratio Mismatch Correction  verexcitation Protection  ransformer Overload Protection  requency Rate-of-Change Detection  ottest Spot Monitoring  otal Harmonic Distortion (THD) The GE Multilin 745-W2-P5-G5-HI-A-R Relay is an essential component in transformer management systems, designed to extend system life by minimizing stress on transformer elements through dynamic CT ratio mismatch correction, overexcitation protection, transformer overload protection, and frequency rate-of-change detection. This relay system incorporates a smart monitoring feature for the hottest spot on the transformer, providing proactive insights to users to prevent potential issues before they escalate. It offers comprehensive protection with its total harmonic distortion (THD) monitoring capability, ensuring optimal electrical performance.

 With its robust design and user-friendly interface, the GE Multilin 745-W2-P5-G5-HI-A-R Relay simplifies the process of managing transformer conditions, enabling operators to monitor and control transformer operations with ease, enhancing efficiency and reducing downtime.

 Equipped with a versatile range of features, this relay is compatible with various industrial applications, making it a reliable choice for transformer protection and management. Its compact size and compatibility with standard mounting panels facilitate easy integration into existing systems. Backed by GE  commitment to quality and innovation, the GE Multilin 745-W2-P5-G5-HI-A-R Relay is engineered to deliver exceptional performance, ensuring peace of mind for users seeking robust transformer protection solutions for their industrial control systems. The GE 745-W2-P5-G5-HI-A-R-E RELAY from GE-FANUC is designed for managing and protecting transformers, autotransformers, and reactors in industrial control systems. Its advanced features ensure reliable operation under various conditions.

C697MDL254 48 VAC input (32 points)

IC697VDD100 24 VDC source, 64 points,

IC697MDL340 120 VAC output, 2 amps (16 points)

IC697MDL740 24/48 VDC output, 2 Amp, positive logic (16 points)

IC697MDL341 120/240 VAC isolated output, 2 amps (12 points)

IC697MDL750 24/48 VDC output, 0.5 amp, positive logic (32 points).

IC697MDL350 120 VAC output, 0.5 amp (32 points)

IC697MDL752 12 VDC output, 0.5 amp, positive logic (32 points)

IC697MDL940 relay output, signal, 2 amps (16 points)

IC697MDL753 5/48 VDC output, 0.5 amp, negative logic (32 points).

IC697VDR150 relay output, non-latched, 2 amps (32 points)

IC697VDQ120 digital output, 64 points.

IC697VDR151 relay output, not latched (64 points)

IC697ALG230 voltage/current, 8 channels

IC697VAL216 16 channels, jumper can choose 16-bit resolution.

IC697ALG440 analog input expander, current, 16 channels.
