BECKHOFF C3640-0050 Build-in Industrial PCs

Appropriate Use

The C3620 and C3640 Industrial PCs are designed for mounting in control

cabinets in machine and plant engineering applications.

After loosening the two screws (see arrows) the front of the PC with TFT

display can be opened, thus providing access to the drive (optional),

3½“ hard disk, processor, memory and plug-in cards.

An ATX motherboard with seven slots for plug-in cards is located behind

the removable card holder and the swivel-mounted power supply unit.

The connections of the Industrial PC to the outside are located on top of

the housing.

After loosening the two screws (see arrows) the front of the PC with TFT

display can be opened, thus providing access to the drive (optional),

3½“ hard disk, processor, memory and plug-in cards.

An ATX motherboard with seven slots for plug-in cards is located behind

the removable card holder and the swivel-mounted power supply unit.

The connections of the Industrial PC to the outside are located on top of

the housing.

Optional the Industrial PC is fitted with a CD/ DVD-drive.

The drive is located at the rear side of the PC.

Interfaces up to C3620/ C3640-0040

PS/2 connections

The upper PS/2 connector (1) allows a PS/2 mouse to be used, while a PC

keyboard can be connected to the lower PS/2 connector (2).

Parallel interface

Printer

LPT1

RS 232

COM1 – COM2

VGA

USB1 – USB4

The parallel interface (3) corresponds to the Centronics standard, and is

addressed by the software as LPT1.

Serial interfaces

The basic version of the Industrial PC has two serial interfaces,

COM1 (4) and COM2. using the type RS 232. which are each

brought to a 9 pin SUB-D plug connector.

The interface COM2 is located in the upper part of the first slot

right beside the ATX-slot.

VGA connection

A 15-pin SUB-D socket connector (5) allows a VGA monitor to be

connected.

USB interfaces

COM2

The four USB interfaces (6 - 9) are used to connect peripheral devices with

USB connections. USB2.0 standard is supported.

Network connection

Network

Sound

Type plate

C3620. C3640

The RJ-45 connector (10) allows the PC to be connected to a Local Area

Network (LAN).

Sound-On-Board

The Industrial PC has a on-board-interface with the following connectors:

Line In jack (11), Line Out jack  (12) and Microphone jack (13).

Additional plug-in cards (optional)

There is a type plate on the top of the Industrial PC which provides

information about the hardware configuration of the Industrial PC at the

time it was supplied

PS/2 connections

X109

X108

X116

X113

X111

X110

X115

X114

The upper PS/2 connector (X104) allows a PS/2 mouse to be used, while a

PC keyboard can be connected to the lower PS/2 connector (X103).

Serial interfaces

RS 232

COM1 – COM2

USB1 – USB4

The basic version of the Industrial PC has two serial interfaces,

COM1 (X105) and COM2. using the type RS 232. which are each

brought to a 9 pin SUB-D plug connector.

The interface COM2 is located in the upper part of the first slot

right beside the ATX-slot.

USB interfaces

COM2

The four USB interfaces (X108 – X111) are used to connect peripheral

devices with USB 2.0 connections.

Network connection

LAN1

LAN2

Sound

DVI-I out

DVI-D out

DisplayPort

Type plate

10

The RJ-45 connector (X112) allows the PC to be connected to a

10/100/1000BASE-T Local Area Network (LAN).

The RJ-45 connector (X113) allows the PC to be connected to a

10/100/1000BASE-T Local Area Network (LAN).

Sound-On-Board

The Industrial PC has a on-board-interface with the following connectors:

Line In (X116), Line Out (X115) and Microphone jack (X114).

DVI-I (Digital Visual Interface)

The DVI connection (X117) is used for transferring the video signal. DVI-I

standard is supported.

DVI-D (Digital Visual Interface)

The DVI connection (X118) is used for transferring the video signal. DVI-D

standard is supported.

DisplayPort

The DisplayPort (X119) is used for transferring the video signal.

Additional plug-in cards (optional)

There is a type plate on the top of the Industrial PC which provides

information about the hardware configuration of the Industrial PC at the

time it was supplied.
