ABB PFVL141V-1.0MN high-precision, heavy-duty rectangular load cell

ABB  PFVL141V-1.0MN   high-precision, heavy-duty rectangular load cell

About this Manual

This manual describes the general function and design of the Pressductor® load cells QGPR 102

and QGPR 104. The purpose is also to be a guidance for installation, commissioning, maintenance

and fault tracing.

Normally, a complete measuring system consists of two load cells with their attached matching

devices, one junction box and one control unit.

The difference between QGPR 102 and QGPR 104 is the installation height (core thickness) of the

load cell:

h= QGPR 102 installation height = 74 ± 0.1 mm

h= QGPR 104 installation height = 57 ± 0.1 mm
