PMC-5565PIORC-211000 VMIC Reflective Memory Card

Product overview

PMC-5565PIORC-211000 is a high-performance  Reflective Memory module produced by VMIC (now belonging to GE intelligent platform). It is designed with PMC(PCI Mezzanine Card) interface, which is suitable for real-time data sharing and distributed system synchronization.

Core characteristics

High-speed data transmission: 2.12 Gbps communication rate is realized through optical fiber network to ensure low delay (typical value < 500ns).

Real-time data sharing: supports deterministic data synchronization between multiple nodes, and is suitable for key applications such as aviation, military industry and industrial automation.

Memory capacity: 64MB of global shared memory (expandable configuration).

Protocol support: compatible with VME/VXI/PCI/CompactPCI system, suitable for various embedded platforms.

technical parameter

The interface standard PMC (PCI Mezzanine Card) is compatible with PCI 32-bit/33MHz.

Optical fiber interface 2x ST/LC multimode fiber (wavelength 850nm, maximum transmission distance 300m)

The transmission rate is 2.12 Gbps (full duplex)

Memory type 64MB SDRAM (configurable in shared or independent mode)

Operating temperature-40 C to+85 C (industrial grade)

Power demand+3.3vdc, typical power consumption 5W.

Typical application

Avionics: flight simulator, avionics test system

Military system: radar data processing, tactical communication network

Industrial Automation: Real-time Control and Machine Vision Synchronization

Scientific research experiment: high-energy physics data acquisition

System integration and configuration

Hardware installation:

Insert PMC compatible slot (PCI specification required).

Connect the optical fiber network (ensure that the ST/LC connector is clean).

Software support:

The driver is compatible with VxWorks, Linux and Windows RTX.

Provide API libraries (C/C++, LabVIEW, etc.).

Maintenance and fault diagnosis

Status indication:

LED indicators (PWR, LINK, ACT) are used for rapid diagnosis.

Frequently asked questions:

The optical fiber link is broken → Check the connector or replace the optical fiber.

Data out of sync → Verify network configuration and clock source.
