AC 900F controller ABB

The AC 900F controller consists of a CPU module, which is the main component. According to the application and requirements, fieldbus modules and I/O modules can be added to the controller. Optionally, AC 900F supports redundancy.

The AC 900F consists of:

Plus CPU module PM 904F who expands the capability of the Standard version PM 902F and supports up to four communication interfaces for PROFIBUS or CAN as well as more application memory.

Standard CPU module PM 902F with four Ethernet interfaces, one diagnostic interface, two serial interfaces and display unit (optional). It supports up tp two communication interfaces.

Lite CPU module PM 901F with three Ethernet interfaces, one diagnostic interface, two serial interfaces and display unit (optional). It supports up to two communication interfaces.

Up to ten S700 I/O modules directly attached on terminal units

The controller supports remote I/Os, transmitters, actuators, drives and other devices, for example through PROFIBUS and other fieldbus protocols.

More power than any previous generation controller

Up to four (PM 904F) or up to two (PM 902F/PM 901F) communication interfaces for PROFIBUS or CAN

Connectivity with 2 serial ports and 4 Ethernet ports (3 with PM 901F)

SD card support for easy controller backup and firmware update

Ethernet based protocols: Modbus TCP, IEC 60870-5-104

G3 compliant for use in harsh environments

Optional LCD for easy access to status and diagnostics information

Small footprint

Optional redundancy for higher availability

AC 900F Overview of Technical Data

CPU  Power PC (II Pro family)

RAM

PM 904F: 48 MB (16 MB battery buffered)
PM 902F: 24 MB (8 MB battery buffered)
PM 901F: 11 MB (3 MB battery buffered)

SD card support For controller backup and firmware update

Display  64x128 Dot Matrix LCD (optional)
