Emerson Ovation controller model OCR1100

The result is undisturbed failover, even in the event of a failure. A series of events may trigger automatic failover, including: control processor failure, network controller failure, I/O interface failure, power cut-off of the control processor, and power control processor reset. Once the control is handed over to the backup processor, the failed processor can be powered off, repaired and re-powered, and the control strategy will not be implemented. After restarting, the repaired processor will detect that its partner is in control and assume the backup role. The processor in control will detect the existence of the backup processor and adjust the redundant operation. Data transfer OCR1100 controller can transfer the information of intelligent field devices to any workstation on Ovation network. Users can use asset management solutions, such as Emerson's AMS suite, to remotely manage equipment in smart sites. The open architecture of Ovation OCR1100 controller in open building uses powerful real-time operating system, and runs CompactPCI i-bus PC to design this configuration, which makes the rapidly developing technology easy to integrate into the control system, while protecting software investment. Real-time operating system function OCR1100 controller real-time data processing control and communication function commercial, multi-tasking, real-time operating system. It executes and coordinates the control of multiple application fields by using multi-tasks with preemptive priority scheduling. Real-time operating system, Ovation communication network and other systems provide some basic routing functions and general resource management in the controller through TCP/IP protocol. Hardware Ovation OCR1100 controller is designed to use Intel processor and industry standard CompactPCI bus technology. The updated technology can be easily merged while protecting the initial Ovation controller software investment. This foundation provides portability, and Ovation controller software can be used in other available platforms and operating systems. The application system of Ovation Virtual Controller in Ovation Simulator runs standard Windows operating system on standard PC hardware, and no actual input/output interface is needed. Hardware platform and operating system Ovation controller are based on industry standards, which provide the following advantages: the hardware cost and complexity are the lowest, the software upgrade improves the ability to track the progress of technology, and the Ovation controller hardware platform has been developed over time, starting with OCR161 model. See the table in this document for the specifications of OCR1100 model. The OCR1100 controller model shares the same packaging concept as the previous OCR400 model. Migrator can be used to update the previous model control logic and upgrade the database to the latest model. The OCR1100 platform provides backward hardware compatibility, which can be used as OCR400, while retaining the following functions. When installed in, OCR1100 platform provides complete OCR1100 functions to support their Ovation system versions (i.e. Ovation 3.5 and above). I/O capability Ovation controller supports concurrent use of several I/O systems depending on the model used. Like controllers, I/O systems are constantly developing, including modules that support increasing channel capacity.

I/O reference manual for available models, capacities, module capabilities and termination types. Ovation controller cabinet Ovation controller and I/O module are installed by DIN rails, providing flexibility to match the controller, layout location, environment and space availability of various process requirements. This normal configuration is to install the DIN rail in and then can be installed in the existing or new cabinet shell. The top and bottom inlet cables of I/O can meet the required specifications. Various controller and I/O cabinet configurations are available. The basic controller cabinet is equipped with a branch in front of the chassis plate for single or redundant controllers and two I/O. Installed on the rear panel are a redundant power supply, a power distribution module and two additional I/O branches for a total of 32 I/O modules, because each I/O branch can accommodate up to eight I/O modules. The expansion cabinet can accommodate up to 32 additional modules in four branches of I/O and the connection of a transition panel controller. It can also provide extra space power supply (when needed) and power distribution module for installing redundant power supply. Ovation's standard cabinet structure is front and rear entrance, but it can only be accessed from the front. Other customized or OEM cabinet housings are available for specific plate size, cabinet size, building materials, environmental grade, cabinet internal and external accessories, termination options and cabinet finishing. ISO organization of International Electrotechnical Commission (IEC), which conforms to IEC 61131-3 standard, has created a set of standards to realize the unified mechanism of configuration and programming control. IEC Part 3, 61131, is directly related to standard programming and recommends languages conforming to this standard. IEC 61131 standard stipulates the syntax and semantic language of unified programming suite, including software model and structured language. Standards can be summarized and described under two main categories: common elements and programming languages. Please refer to the international standard of the detailed information table that Ovation Ovation complies with IEC 61131-3 data. Achilles Certification Achilles Communications Certification provides industry-leading security benchmarks for the development of applications, equipment and systems found in critical infrastructure. The purpose of the certification process is to evaluate the robustness of industrial equipment on the network and prove that they meet a comprehensive set of requirements. It provides the possibility that manufacturers with independent verification results can convey the safety of their products to customers, and at the same time provide the most complete, accurate and trustworthy information about the flexibility of their deployed networks for control system operators. Ovation OCR1100 controller meets the requirements of Achilles Level 1 certification. Ovation system provides excellent precision control. That precision begins with the Ovation controller, which provides complete redundancy to ensure reliability and security applications that even the most demanding requirements must have. Ovation controller implements simple or complex modulation and sequence control strategies, performs data acquisition functions and combines fully undisturbed redundant applications with key tasks. The controller provides the following functions in an adaptable, flexible and cost-effective way. With industry-standard hardware and software platform controllers, it is easy to upgrade the life cycle throughout the factory. These characteristics make Ovation controller one of the most powerful in the industry.
