CP29xx-0000 | Multi-touch built-in Control Panel with DVI/USB Extended interface

Balance between latest PC technology and long-term availability of control components

Modern Control Panel technology doesn't stop with the selection of the touch technology, which forms the basis of the operation of a machine or plant.

The transmission of the image and touch signals, combined with the power supply or other digital signals, must work perfectly and continuously,

both mechanically and electrically, and over long distances in the industrial environment.

In order to reliably ensure this, Beckhoff installs Panel electronics that it develops and manufactures itself at the production location in Verl.

Product variants    Transmission technology    Product status

CP29xx-0010    CP-Link 4    regular delivery

CP29xx-0000    DVI/USB Extended    regular delivery

Technical data    CP29xx-0000    Options

Device type    Multi-touch built-in Control Panel with DVI/USB Extended interface

Housing    aluminum housing with glass front    stainless steel housing with glass front at 7", 12.1", 15", 15.6", 18.5" and 21.5" display

Display size/resolution    7" 800 x 480. 12" 800 x 600. 12.1" 1280 x 800. 15" 1024 x 768. 15.6" 1366 x 768. 18.5" 1366 x 768. 19" 1280 x 1024. 21.5" 1920 x 1080 or 24" 1920 x 1080

Touch screen    multi-finger touch screen

Protection rating    front side IP65. rear side IP20

Connection technology    DVI-E and USB-E enables to connect the Control Panel at a distance of up to 50 m to the PC. The DVI-E input is compatible to the standard DVI output of a PC. USB-E 2.0 transmits USB 2.0 with 480 Mbit/s.

Interfaces    RJ45 for USB-E 2.0. USB 3.0 input for the direct connection to the standard USB output of a PCs at a distance up to 5 m, DVI input, 2 x USB 3.0 (at more than 3 m distance to the PC limited to USB 2.0)    1 x USB in the front

Operating temperature    0…55°C

Installation    pull-out clamping levers for fast installation without loose parts

Power supply    24 V DC

CP29xx-0000    Multi-touch built-in Control Panel with DVI/USB Extended interface

CP2907-0000    7-inch display 800 x 480. display only, multi-finger touch screen with DVI/USB Extended

CP2912-0000    12-inch display 800 x 600. display only, multi-finger touch screen with DVI/USB Extended

CP2913-0000    12.1-inch display 1280 x 800. display only, multi-finger touch screen with DVI/USB Extended

CP2915-0000    15-inch display 1024 x 768. display only, multi-finger touch screen with DVI/USB Extended

CP2916-0000    15.6-inch display 1366 x 768. display only, multi-finger touch screen with DVI/USB Extended

CP2918-0000    18.5-inch display 1366 x 768. display only, multi-finger touch screen with DVI/USB Extended

CP2919-0000    19-inch display 1280 x 1024. display only, multi-finger touch screen with DVI/USB Extended

CP2921-0000    21.5-inch display 1920 x 1080. display only, multi-finger touch screen with DVI/USB Extended

CP2924-0000    24-inch display 1920 x 1080. display only, multi-finger touch screen with DVI/USB Extended

Options    Multi-touch built-in Control Panel with DVI/USB Extended interface

C9900-T327    18.5-inch display with Full HD resolution 1920 x 1080. instead of standard resolution 1366 x 768

C9900-M575    vertical orientation of the display inside the Control Panel or Panel PC CP22xx, CP26xx, CP29xx or CP39xx instead of standard Control Panel or standard Panel PC

C9900-E268    1-port USB socket inside the front of a CP2xxx without push-button extension, USB-A socket IP65

C9900-F941    stainless steel front with blue silicone seal for CP2x07-00x0 for horizontal alignment, stainless steel 1.4404. matt ground with grain size 240. instead of standard aluminum front

C9900-F942    stainless steel front with blue silicone seal for CP2x13-00x0 for horizontal alignment, stainless steel 1.4404. matt ground with grain size 240. instead of standard aluminum front

C9900-F944    stainless steel front with blue silicone seal for CP2x15-00x0 for horizontal alignment, stainless steel 1.4404. matt ground with grain size 240. instead of standard aluminum front

C9900-F945    stainless steel front with blue silicone seal for CP2x16-00x0 for horizontal alignment, stainless steel 1.4404. matt ground with grain size 240. instead of standard aluminum front

C9900-F946    stainless steel front with blue silicone seal for CP2x18-00x0 for horizontal alignment, stainless steel 1.4404. matt ground with grain size 240. instead of standard aluminum front

C9900-F948    stainless steel front with blue silicone seal for CP2x21-00x0 for horizontal alignment, stainless steel 1.4404. matt ground with grain size 240. instead of standard aluminum front

C9900-K622    Connecting kit for CP29xx-0000 and CPX29xx-0000 including C9900-K549 DVI cable, C9900-K569 USB 3.0 cable (1.00 m) – 1.00 m

C9900-K623    Connecting kit for CP29xx-0000 and CPX29xx-0000 including C9900-K550 DVI cable, C9900-K570 USB 3.0 cable (3.00 m) – 3.00 m

C9900-K624    Connecting kit for CP29xx-0000 and CPX29xx-0000 including C9900-K527 DVI cable, C9900-K553 USB 2.0 cable (5.00 m) – 5.00 m

C9900-K625    Connecting kit for CP29xx-0000. CPX29xx-0000 and CP69xx-xxxx-0010 including C9900-K528 DVI cable, C9900-K538 USB Extended cable, CU8801-0000 USB extension, C9900-K554 USB 2.0 cable (1.00 m) – 10.00 m

C9900-K626    Connecting kit for CP29xx-0000. CPX29xx-0000 and CP69xx-xxxx-0010 including C9900-K534 DVI cable, C9900-K539 USB Extended cable, CU8801-0000 USB extension, C9900-K554 USB 2.0 cable (1.00 m) – 20.00 m

C9900-K627    Connecting kit for CP29xx-0000. CPX29xx-0000 and CP69xx-xxxx-0010 including C9900-K535 DVI cable, C9900-K540 USB Extended cable, CU8801-0000 USB extension, C9900-K554 USB 2.0 cable (1.00 m) – 30.00 m

C9900-K628    Connecting kit for CP29xx-0000. CPX29xx-0000 and CP69xx-xxxx-0010 including C9900-K536 DVI cable, C9900-K541 USB Extended cable, CU8801-0000 USB extension, C9900-K554 USB 2.0 cable (1.00 m) – 40.00 m

C9900-K629    Connecting kit for CP29xx-0000. CPX29xx-0000 and CP69xx-xxxx-0010 including C9900-K537 DVI cable, C9900-K542 USB Extended cable, CU8801-0000 USB extension, C9900-K554 USB 2.0 cable (1.00 m) – 50.00 m

C9900-K774    Connecting kit for CP29xx-0000 and CPX29xx-0000 including C9900-K780 DisplayPort cable, C9900-K569 USB 3.0 cable (1.00 m) – 1.00 m

C9900-K947    Connecting kit for CP29xx-0000 and CPX29xx-0000 including C9900-K820 DisplayPort cable, C9900-K577 USB 3.0 cable (2.00 m) – 2.00 m

C9900-K775    Connecting kit for CP29xx-0000 and CPX29xx-0000 including C9900-K781 DisplayPort cable, C9900-K570 USB 3.0 cable (3.00 m) – 3.00 m

C9900-K776    Connecting kit for CP29xx-0000 and CPX29xx-0000 including C9900-K782 DisplayPort cable, C9900-K553 USB 2.0 cable (5.00 m) – 5.00 m

Material compliance    CP29xx-0000

CAS No.    7439-92-1. 80-05-7. 552-30-7

REACH SVHC    Lead, 4.4-Isopropylidendiphenol, 1.2.4-Benzenetricarboxylic anhydride

REACH Annex XVII    compliant

REACH Annex XIV    compliant

POP    compliant

RoHS    compliant with exemption

RoHS exemption    6c: Copper alloy with a mass fraction of up to 4% lead, 7c-I:

Lead-containing electrical and electronic components in glass and ceramic materials, excluding dielectric ceramics in capacitors

China-RoHS    www.beckhoff.com/china-rohs-ipc

CA Prop65    www.beckhoff.com/prop65

Disclaimer    This statement and the information contained above are, to the best of our knowledge and belief, accurate,

based on the information we have received from our suppliers.

This information is in line with the current standard of technology and our suppliers’ technical documentation.

The absence of the substances is not verified by Beckhoff Automation by means of analytical tests.

When addressed to our customers any information contained in this document is subject to the terms and conditions expressed in the governing customer agreement.

 Our general terms and conditions apply.

Material compliance | SCIP    SCIP No.

CP29xx-0000    SCIP submission in progress

CP29xx-0000    SCIP submission in progress

CP29xx-0000    SCIP submission in progress

CP29xx-0000    SCIP submission in progress

CP29xx-0000    SCIP submission in progress

CP29xx-0000    SCIP submission in progress

CP29xx-0000    SCIP submission in progress

CP29xx-0000    SCIP submission in progress

CP29xx-0000    SCIP submission in progress
