KJ3242X1-BK1 S-Series H1 Card

 Hazardous Atmosphere

II 3G Ex ec IIC Gc

FM19ATEX0173U

IECEx FMG 19.0019U

 FM21UKEX0017U

 II 3G Ex nA nL IIC Gc

Nemko 10ATEX3225U

 IECEx NEM 10.0019U

 CL. I Div. 2 GP. A,B,C,D

 CL. I Zone 2 AEx/Ex ec IIC Gc

FM17US0286U

 FM17CA0145U

 Power Specifications

Local Bus Power

Fieldbus Power

12 VDC at 300 mA

9 to 32 VDC at 12 mA/Port

Environmental Specifications

Ambient

Temperature

Shock

Vibration

Airborne

Contaminants

Relative Humidity

Terminal Block key

Position  -40°C to +70°C

 10g ½ Sinewave for 11msec

1mm Peak to Peak from 2 to 13.2Hz;

0.7g from 13.2 to 150Hz

ISA-S71.04 –1985 Airborne

Contaminants Class G3

5 to 95% Non-Condensing

Note: Refer to the product label for serial number

and location and date of manufacture.

Warning: This product has specific instructions for

installation, removal and operation in hazardous

areas. Refer to document 12P5404 "DeltaV™ S

Series Digital Automation System Zone 2 Installation

Instructions".  Other installation instructions are

available in the "DeltaV™ S-Series and CHARMs

Hardware Installation" manual.

Removal and Insertion

Field power supplied to this device, either at the field

terminal or as bussed field power through the

Carrier, must be removed before removing or

connecting the device.

This unit cannot be removed or inserted with system

power energized.

For “nL” installation, an I/O loop assessment must

be completed on all energy-limited nodes.

A rotary keying system ensures compatibility

between I/O cards and terminal blocks after

installation is complete. The terminal block must

have the keys set for the I/O card with which it is

used.

Maintenance and Adjustment

This unit contains no user serviceable parts and

should not be disassembled for any reason.

Calibration is not required.
