Shinkawa VM-721B 18-CHANNEL RELAY MODULE

Shinkawa VM-721B 18-CHANNEL RELAY MODULE

UTPUT

Indicators : ACTIVE LED (Green)

On : Normal

Flash : The module is installed in slots other

than Slot 11

Contact output  : Number of outputs : 18 points(logic changeable)

Contact type : Dry contact (SPST)

Select for N.O. / N.C. contact by internal jumper.

Enagization method: Normally de-energized or

Normally energized field

changeable

Contact capacity : 250VAC / 5A, 30VDC / 5A

ENVIRONMENTAL CONDITION

Operating temperature  :  0 to +65°C

Operating temperature at explosion proof construction

:  0 to +60°C

Storage temperature  :  -30 to +85°C

Relative humidity  :  20 to 95%RH (non-condensing)

POWER CONSUMPTION

Module  : Less than 15W

MATERIAL AND FINISH

Face plate : ABS (Black)

Sheet : Polyester tough top (Gray)

Base plate : Alminium alloy (Silver)

MASS

Body            : Max. 1.0kg (2.2lb)

ACCESSORY SPECIFICATION CODE / IDENTIFIED BY TB□

Code Accessory Quantity

(Part Code)

/TB1 18 channel relay module output terminal block plug (18pin)

FRONT-MC-1.5/18-STF-3.81 (PHOENIX CONTACT)

2pieces *1

(7072NAA)

/TB2 18 channel relay module output terminal block plug (18pin)

FRONT-MC-1.5/18-STF-3.81 (PHOENIX CONTACT)

2pieces *1

(7072NAA)

Note)*1  When individually ordering specify the parts code,it is require to arrange

for a necessary amount.

OTHERS

Note) The relay module is possible to install only one module in a rack.

The module should be install to slot. 11.

VM-772B Device Config is necessary to program the logic of output

contact.

CONTACT OUTPUT

Contact (RELAY1) : Slot 1 DANGER

Contact (RELAY2) : Slot 1 ALERT

Contact (RELAY3) : Slot 2 DANGER

Contact (RELAY4) : Slot 2 ALERT

Contact (RELAY5) : Slot 3 DANGER

Contact (RELAY6) : Slot 3 ALERT

Contact (RELAY7) : Slot 4 DANGER

Contact (RELAY8) : Slot 4 ALERT

Contact (RELAY9) : Slot 5 DANGER

Contact (RELAY10) : Slot 5 ALERT

Contact (RELAY11) : Slot 6 DANGER

Contact (RELAY12) : Slot 6 ALERT

Contact (RELAY13) : Slot 7 DANGER

Contact (RELAY14) : Slot 7 ALERT

Contact (RELAY15) : Slot 8 DANGER

Contact (RELAY16) : Slot 8 ALERT

Contact (RELAY17) : Slot 9 DANGER

Contact (RELAY18) : Slot 9 ALERT

CONTACT OUTPUT

Enagization method : Normally de-energized

Contact Type : N.O. (Normally Open) Contact

OTHERS

Contact type Enagization method Power OFF

Power ON

Normal state Alarm state

N.O. contact

NORMALLY DE-ENERGIZED OPEN OPEN CLOSE

NORMALLY ENERGIZED OPEN CLOSE OPEN

N.C. contact

NORMALLY DE-ENERGIZED CLOSE CLOSE OPEN

NORMALLY ENERGIZED CLOSE OPEN CLOSE

Alarm Contact Operation

Default Value

Specification

Model Code / Additional Spec. Code (                 ) No entry if additional

spec, code is not specified.
